Description

The Trek Madone SLR 9 AXS 1x Gen 8 is our lightest Madone disc ever. Weighing just 6.4 kg, it’s 400 g lighter than the UCI minimum weight requirement while maintaining the aero efficiency Madone is known for. Fly up climbs and across flats with ultralight build details like a SRAM RED 1×12 drivetrain, feathery Aeolus RSL 37 wheels and an optional lightweight Matt Deep Smoke colourway.

Why buy from Spokerite

Spokerite is the online store of CycloPro, an authorised Trek dealer at Walmer Downs in Gqeberha. When you order this bike from us, our own workshop mechanics assemble and safety-check it. It arrives ready to ride. Because we are an authorised dealer, Trek’s official warranty covers your bike. You also get a local workshop for setup, bike fitting and servicing.

Not sure if this is the right bike for you? Browse our other road bikes or contact our team for advice. You can also read more about this model on Trek’s official website.

Trek Madone SLR 9 AXS 1x specifications

Frameset

Fork

Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12×100 mm chamfered thru axle

Wheels

Wheel rear

Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142 x 12 mm thru axle

Tyre

Pirelli P Zero Race RS, 120 tpi, 700×28 mm

Wheel front

Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle

Valve

Bontrager XXX TLR valve, 55 mm

Skewer front

Bontrager Switch chamfered thru axle

Skewer rear

Bontrager Switch chamfered thru axle, removable lever

Drivetrain

Chain

thSRAM RED E1

Crank

SRAM RED E1, power meter, 48T, DUB, 165 mm length (XS, S)
SRAM RED E1, power meter, 48T, DUB, 170 mm length (M, ML)
SRAM RED E1, power meter, 48T, DUB, 172.5 mm length (L, XL)

Rear derailleur

SRAM RED AXS E1, 36T max cog

Cassette

SRAM RED XG-1290 E1, 10-36, 12-speed

Bottom bracket

SRAM DUB, T47 threaded, internal bearing

Shifter

SRAM RED AXS E1

Components

Saddle

Aeolus RSL, carbon rails, 145 mm width

Seatpost

Madone aero carbon seat post, 0 mm offset, short length

Handlebar tape

Trek gel cork

Brake rotor

SRAM Paceline X, rounded, CentreLock, 160 mm

Brake

SRAM Red AXS E1 hydraulic disc, flat mount

Electric parts

Battery

SRAM AXS battery pack (with charger)

Accessories

Tube

Pirelli P Zero SmarTube, TPU

Headset part (see also: Bearing)

Bontrager Headset Expander Plug and Top Cap

Hub body

DT Swiss 240 alloy, sealed cartridge bearing, CenterLock, SRAM XD-R driver, 142×12 mm thru axle

Frame with Fork

900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142×12 mm thru axle

Handlebar/stem (integrated)

Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length (XS)
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length (S)
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length (M)
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length (ML, L)
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length (XL)

Trek may change specifications without notice. Please confirm the spec with us before you order.
