Description

The Trek Checkpoint SL 7 AXS is part of Trek’s 2027 gravel bike range. The Checkpoint SL 7 AXS Gen 3 is a carbon gravel bike built to explore the beyond. Its lightweight carbon frame is designed with a Gravel Endurance geometry, tons of mounts and clearance for up to 50 mm tyres (as measured). Plus, IsoSpeed comfort tech helps soak up jarring vibrations so you can float over chatter and potholes. It’s decked out with upgrades where you want them most, like carbon wheels and seat post, and a wireless SRAM Force AXS XPLR E1 drivetrain.

Why buy from Spokerite

Spokerite is the online store of CycloPro, an authorised Trek dealer at Walmer Downs in Gqeberha. When you order this bike from us, our own workshop mechanics assemble and safety-check it. It arrives ready to ride. Because we are an authorised dealer, Trek’s official warranty covers your bike. You also get a local workshop for setup, bike fitting and servicing.

Not sure if this is the right bike for you? Browse our other gravel bikes or contact our team for advice. You can also read more about this model on Trek’s official website.

Trek Checkpoint SL 7 AXS specifications

Frameset

Frame

500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142×12 mm chamfered thru axle

Fork

Trek Checkpoint, full carbon, tapered steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle

Wheels

Valve

Bontrager XXX TLR valve, 55 mm

Skewer rear

Bontrager Switch chamfered thru axle, removable lever

Wheel rear

Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, SRAM XD-R driver, 142×12 mm thru axle

Tyre

Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700×42 mm

Tyre part

Bontrager TLR sealant, 180 ml/6 oz

Wheel front

Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, 100×12 mm thru axle

Skewer front

Bontrager Switch chamfered thru axle

Rim strip

Bontrager TLR

Drivetrain

Chain

SRAM Force E1, 12/13-speed

Crank

SRAM Force E1 XPLR, 40T, DUB Wide, 160mm length (XS, S)
SRAM Force XPLR, 40T, DUB Wide, 165 mm length (M, ML)
SRAM Force XPLR, 40T, DUB Wide, 170 mm length (L, XL)

Rear derailleur

SRAM Force XPLR AXS, 46T max cog

Cassette

SRAM Force XPLR XG-1371, 10-46, 13-speed

Bottom bracket

SRAM DUB Wide, T47 threaded, internal bearing

Shifter

SRAM Force AXS E1

Components

Stem

Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length (XS)
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80mm length (S, M)
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 90mm length (ML, L)
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 100mm length (XL)

Saddle

Verse Short Elite, hollow magnesium rails, 145 mm width

Handlebar

Bontrager Pro Gravel, 40 cm width (XS, S)
Bontrager Pro Gravel, 42 cm width (M, ML)
Bontrager Pro Gravel, 44 cm width (L)
Bontrager Pro Gravel, 46 cm width (XL)

Brake rotor

SRAM CentreLine X, CentreLock, round edge, 160 mm (XS, S, M, ML, L, XL)
SRAM Paceline X, rounded, CentreLock, 160 mm (XS, S, M, ML, L, XL)

Brake

SRAM Force AXS hydraulic disc, flat mount

Seatpost

Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length

Handlebar tape

Bontrager Supertack Perf tape

Electric parts

Battery

SRAM AXS battery pack (with charger)

Accessories

Headset part (see also: Bearing)

Bontrager Headset Expander Plug and Top Cap

Bag

Bontrager BITS Internal Frame Storage Bag

Trek may change specifications without notice. Please confirm the spec with us before you order.
